Use your pipes for a longer period

NMR Pipetector extends the life expectancy of old pipes as long as that of buildings by changing internal red rust to black rust, a water-insoluble substance. With this, you do not have to go through pipe replacement that causes CO2 emissions when constructing new ones.

NMR Pipetector

Extending lifespan of pipes for over 40 years

Steel pipes can be used for about 20 years in general. However, NMR Pipetector allows us to use the pipes for more than 40 years without being bothered by corrosion. In fact, NMR Pipetector has many case studies to support this. For example, the Teigeki building and a major DPE factory have used their pipes for 55 years; the Yaesu Guchi Kaikan building has used its pipe for 56 years.

What is black rust?

Black rust has a chemical property that does not dissolve in water and has a hard lattice structure with a volume of less than 1/10 of that of red rust.
Because black rust forms a dense film on the surface of metals and is resistant to corrosion, it is used to coat the surface of iron products, such as woks and steam locomotives. It has also been used for nails and hinges made way back in the Nara and Heian periods (between 710 and 1185), protecting the iron products from corrosion deterioration for centuries.

Converting red rust to black rust, NMR Pipetector stops the elution of iron, leading to the clearing of water discoloration. Eventually, NMR Pipetector removes the blockage caused by red rust, as black rust has a smaller volume than red rust has.

Nambu tetsubin coated with black rust.
Nambu tetsubin teapot coated with black rust

Cost comparison: NMR Pipetector v.s. pipe replacement

Cost Comparison_Hotels

Once you install NMR Pipetector on your old pipes, you will no longer need to replace them. NMR Pipetector costs less than 1/10 of pipe replacement does on average and thus saves facility maintenance cost. The left and below images describe the actual cost merit of NMR Pipetector.

Obviating pipe replacement
Royal Garden Hotel London, UK

The total NMR Pipetector cost was £100 thousand at the hotel, while it could have cost £6.5 to 7 million (£1 = \140) if the hotel were to choose pipe replacement. The hotel achieved to cut its facility cost to 1/65~1/70 in the end.

Realizing zero maintenance cost for pipes

COST

NMR Pipetector does not require maintenance, monthly electricity cost, or cause damage to pipes at all. On the contrary, those pipes gradually gain thickness as NMR Pipetector forms a layer of black rust on the pipe inner surface; in other words, pipe strength increases.

Increasing property value

Palace Tsurumi, an apartment in Yokohama city, Kanagawa Prefecture
Palace Tsurumi, an apartment in Yokohama city, Kanagawa Prefecture

NMR Pipetector largely reduces building maintenance costs, allowing apartments to gain financial leeway in their operating budget. In fact, many buildings have succeeded in improving their asset value through various renovations, such as installing a new elevator, repainting outer walls and waterproofing roofs.

Examples of renovations
Outer wall coating
Outer wall repainting
New elevator
New elevator
Waterproofing on the roof
Roof waterproofing

No pipe cutting or disrupting water supply

No pipe cutting or disruption on water supply.

In general, it costs us extra expense to shut off the water supply during pipe replacement works, in addition to the cost of the work itself. Other conventional methods to deal with rusty pipes may require cutting them.Other conventional methods to deal with rusty pipes may require cutting them.

In contrast, we can install NMR Pipetector by just attaching it around a pipe with a couple of screws. You do not have to cut pipes or turn off water infrastructure; thus, it only takes an hour or two to install the device. It is beneficial at hotels and hospitals, particularly where you cannot shut off the water supply for patients and hotel guests.

*Any installation on underground water mains takes extra time to dig the ground and restore it to its original state.

Safe and hygienic

Does not be in contact with water

Installation
Actual installation

As NMR Pipetector is fitted on the outer surface of pipes, it does not directly contact the water flowing inside pipes throughout the product’s minimum lifespan of 40 years, thus hygienic. NMR Pipetector has gained many reputations for that advantage.

Improves pipe integrity, no chemicals used

Does not damage pipes or require harmful inhibitors

Conventional methods pose a safety risk on tubing, as they require chemical dosing to water and wear off the thickness of pipes when washing inside the lines. NMR Pipetector, as it only needs to be fitted on the outer surface of pipes, does not be in direct contact with water. For this reason, you do not have to dose chemicals or have a fear of damaging your pipes.

Disadvantages of conventional plumbing methods

Replacement of pipes

To replace pipes is the most costly way to address corrosion issues in your pipes. You also have to shut off the water supply, deal with waste materials and a mass amount of CO2, being adversaries to SDGs.

Epoxy coating

Red rust corrosion still grows at pipe joints where you cannot physically implement a coating treatment. Moreover, there is an increased risk of developing cancer if epoxy resin, a carcinogenic substance, elutes in drinking water.

Cathodic protection winding electrode cable around pipes

Wrapping electrode cable around pipes is limited to scale deposits, not for corrosion.

Magnetic products

More than 150 Japanese companies have supplied magnetic devices for the past 3 decades, but none of them was able to show evidence they could prevent corrosion in pipes. As a result, most of those suppliers had to suspend business operations.

Total solution to red rust-relating corrosion

Total solution to corrosion caused by internal red rust
Water molecule
Specific Electromagnetic waves
Chemical formula

NMR Pipetector contains black-body substances formed in the process of sintering 12 types of rare metals. This allows the device to emit electromagnetic waves at a certain frequency towards water pipes. We tested and proved that those waves did not affect the human body in an exam* at Chemicals Evaluation and Research Institute, Japan.

As shown in the testing, the electromagnetic waves generated by the device are weaker than those of home appliances, including cell phones. However, because the safety of the waves is guaranteed as they neither affect cardiac pacemakers or other medical machinery, many Japanese hospitals have adopted NMR Pipetector to their pipework.

The mechanism of the device is this: 1. electromagnetic waves relocate hydrated electrons inside water clusters to their outer surface. 2. the hydrated electrons are then emitted as water flows inside pipes. 3. The emitted electrons adhere to red rust inside pipes, reducing it to black rust.

*Click here to see the test report by Chemicals Evaluation and Research Institute, Japan

Hydrated electrons?

Water molecules in water are aggregated into a large mass called a water cluster. Hydrated electrons, one of the key elements of rust reduction, exist in a water cluster of a group of 64 water molecules or more. Without NMR Pipetector, hydrated electrons are kept inside those water clusters.

Click here to see Products

Worldwide-patented technology

U.S. patent
U.S. patent
Japan patent
Japan patent
S. Korea patent
S. Korea patent
Taiwan patent
Taiwan patent

Treatises accepted by international academic meetings

WCP2018 KYOTO: the 18th World Congress of Basic and Clinical Pharmacology
WCP2018 KYOTO: the 18th World Congress of Basic and Clinical Pharmacology

Three symposiums duly accepted our treatises on the NMR technology. It was the first academic conference ever to accept a paper focused on the technology extending the life expectancy of metallic pipes.

Those research groups are the 13th Asian-Pacific Corrosion Control Conference, the Japan Association of Corrosion Control conference 2005, and the World Pharmaceutical Congress 2010.

Japan Association of Corrosion Control (JACC)

Japan Association of Corrosion Control (JACC)
World Pharmaceutical Congress 2010
World Pharmaceutical Congress 2010

Applicable to any kinds of pipe systems, buildings

Red rust

NMR Pipetector can be used for any type of building. In fact, it is used at apartments, flats, condos, hotels, inns, hospitals, nursing care facilities, commercial facilities, public facilities, factories, bank buildings, schools, office buildings and supermarkets.

NMR Pipetector also fits in with various pipe systems, such as domestic tap, hot, air-conditioning heating, chilled, condenser water pipes and underground water mains.

NMR Pipetector also has many case studies abroad. In the UK, it is used in Buckingham Palace, the Guildhall in London, Palace of Westminster, the British Museum, a BBC building, Whittington Hospital, the Royal Garden Hotel London, the Royal Bank of Scotland, City, University of London and Harrods, among many other renowned buildings.

Client testimonials

Received client testimonaials

NMR Pipetector has acquired favorable reputations on its efficacy and benefits from our customers. We received client testimonials from the Royal Bank of Scotland, Royal Garden Hotel London, the Guildhall in central London and Whittington Hospital, one of the NHS Trust medical facilities.

An innovative device drawing attention of media

Manufacturing Technology Insights

A U.S. technical magazine Manufacturing Technology Insights selected NMR Pipetector as one of the top 10 corrosion control technologies worldwide. The magazine also featured the achievement in its 2020 issue.

News Watch TV

A U.S. consumer-focused TV show News Watch TV on Feb. 12, 2016 featured NMR Pipetector as a new technology holding great expectations. Another U.S. TV program Beyond Future, on Feb. 20 aired NMR Pipetector in the same year as an innovative technology made in Japan.

Several trial options

Per the customer’s actual site conditions, we select the most suitable method for a test trial from one of the following: water sampling, filtering, and testing of black rust ratio.

Three ways of trial

Water sampling, followed by lab testing of iron content in sampled water
An example case of water sampling
Filtering, followed by lab testing of iron content in filters
An example case of filtering
Testing of increased ratio of black rust to red rust in cut pipes
We test the increased ratio of black rust to red rust in a cut pipe.

* Testing period differs depending on customer’s site conditions and trial method

Verified the effectiveness at a third-party institute

The former Hokkaido Industrious Testing Facility
Former Hokkaido Industrious testing facility

We verified NMR Pipetector’s effectiveness on old water pipes with the supervision of Hokkaido University Professor Emeritus Toshio Yuta at the former Hokkaido Industrious testing facility.

The iron level in water was 0.786 mg/L before installation, but it gradually decreased after a month, and after four months, it drastically dropped to 0.262 mg/L. This figure is below the iron level requirement at 0.3 mg/L determined in the Japanese drinking water act.

Click here to see the test report

Agent/agency in charge of trial

Agent/agency responsible for water sampling

A sales agent/agency either samples water or carries out a filtering test in witness of customers. The agent/agency then outsources the analysis of sampled water or a filter to a third-party lab as a part of a test trial.

Reference: a certificate of lab testing from the case study at Royal Garden Hotel London

Rectifies smell and taste of water

NMR Pipetector largely improved the water quality of a condenser water system at an 11-year-old food processing factory in Shizuoka Prefecture, Japan. After installing NMR Pipetector, the number of single-cell bacteria in the condenser water dropped to 270 from 640 per 1 mL. The level of watercolor, which rises as organic matter thrives, also dropped from 8 to 3, a figure within the Japanese water quality requirement.

water

Not only did the number of bacteria lessened, but the level of potassium permanganate also did: its consumption declined from 13.3 mg/L to 11.4 mg/L. Because NMR Pipetector functioned as a total solution to rectify the water quality, the residue on evaporation also dropped to 499 mg/L from 952 mg/L. The level of nitrate-nitrogen, which also increases as organic matter grows in water, significantly sunk to 4.7 mg/L from 13.2 mg/L.

NMR Pipetector kept suppressing the algae growth in a factory’s cooling tower even after the factory cut the chlorine dosage to the condenser system to 1/3.

10-year warranty

10-year warranty

We offer every customer a free replacement for any defective product covered with a 10-year warranty. This warranty is in effect from the day NMR Pipetector is installed.

Maintenance-free

Maintenance-free

NMR Pipetector saves costs of facility maintenance because it is totally maintenance-free once installed.

Free testing inside your pipes

Free testing inside pipes

To assess the degree of corrosion development inside your piping, your agency proposes a pre-exam, such as site survey and water sampling, before installing NMR Pipetector to ensure that the device can actually solve the issues.

Points of attention

Points of attention
  • Buildings need to have a certain daily water consumption: e.g., around 100-200 mL a day per tap.
    * If water consumption is smaller than 100 mg/L a day, it might take 3 to 6 months for NMR Pipetector to be effective.
  • NMR Pipetector deals with internal corrosion stemming from red rust inside pipes, as the reducibility is limited to places where water flows.
  • Although NMR Pipetector can stop the development of new copper corrosion in copper pipes, any existing copper corrosion, i.g. verdigris, cannot be reduced to an insoluble substance, such as magnetite, as there is no such substance for copper.

Our history

The number of buildings that have adopted NMR Pipetector has now reached 4,200 in Japan and 200 abroad.

Japan System Planning Co. has been responsible for selling its own device, NMR Pipetector, that controls corrosion in old pipes for over 25 years. The number of buildings that have adopted NMR Pipetector has now reached 4,200 in Japan and 200 abroad.

Taking actions for the Sustainable Developmental Goals

SUSTAINABLE DEVELOPMENT GOALS

Established in 1988, our company endeavors to contribute to a sustainable society with its own patented technology. Making pipe replacement works unnecessary; the technology can save the energy for making new pipes and reduce waste materials that come from such works.

With a vision of providing eco- and health-friendly products to society, we are committed to achieving the SDGs even further.
